Photo-documented work

Real parts. Real tooling. Real factory.

These factory and product photographs document actual components and tooling. Project-specific drawings and measured results remain confidential; the examples below focus on features visible in the images and the manufacturing routes they illustrate.

01 · CNC milling

Milled mounting brackets with multi-face features.

Photographed finished brackets show flat mounting bases, repeated fastener holes, upright arms and upper connection holes.

Four black CNC-machined mounting brackets with base mounting holes and upright connection arms in a blue factory tray — Actual bracket parts photographed in the production area.

Drawing-based component

What this example shows

The base holes and upright connection features make this a useful example of geometry that requires attention to feature position and perpendicularity. Exact material, coating, dimensional tolerances and end use must be defined by the customer drawing.

Visible result: four matching machined bracket parts
Relevant route: CNC milling and hole-making
Inspection: drawing-critical dimensions can be checked by CMM

Explore CNC milling service →

02 · Mold tooling

Multi-cavity precision mold plate.

The real close-up shows a machined steel tooling plate with repeated cavity features, drilled holes and fine cross-shaped runner details.

Close-up of a precision-machined multi-cavity mold plate with repeated small cavities, holes and runner features — Actual tooling surface and repeated cavity layout.

Precision tooling

What this example shows

Repetition across the plate makes feature consistency and hole location important during mold manufacture. The image documents the tooling, but does not establish a specific resin, shot count, cavity tolerance or production outcome.

Visible result: repeated precision-machined cavity features
Relevant route: mold machining and finishing
Inspection plan follows the controlled tooling drawing

Explore injection mold manufacturing →

03 · CNC turning

Turned metal components assembled as finished products.

The photographed products show cylindrical end pieces and connecting handles in several finished sizes.

Group of finished metal dumbbells with turned cylindrical end pieces and textured connecting handles — Actual finished metal products supplied in the company photo set.

Turned component family

What this example shows

Cylindrical parts and repeated sizes illustrate the kind of work suited to turning, with secondary operations and assembly defined by the design. The photograph alone does not verify alloy grade, weight accuracy or surface-finish specification.

Visible result: multiple sizes of finished metal dumbbell assemblies
Relevant route: CNC turning for circular features
Material identity is confirmed by the supplied material report

Explore CNC turning service →

Project controls

What buyers can request with a real order.

For quoted projects, METIC coordinates the drawing review with Hongye. Material testing reports are available for the materials used, and drawing-critical precision dimensions are checked with coordinate measuring equipment (CMM). The inspection plan and report scope should be agreed during quotation.

Typical lead time is 7–25 days, depending on drawing complexity, material availability, quantity and finishing. This is a planning range, not a guaranteed delivery date for the photographed examples.
